LightBurn-Einstellungen für Gravur

Materials LU2-2 (≤2.1W) LU2-4-SF/LF (=5W) LU2-10A (=10W) LU3-20A/B (=20W) LU3-40A (=40W) LR4-2B (=2W)
MDF Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70
 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 40		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 55		 ×
Plywood Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.1
Speed(mm/m): 15000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 80		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 80		 ×
Pine Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 ×
Paulownia Image Mode: Grayscale
Interval(mm): 0.07
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 10000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.1
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 40		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 ×
Paperboard
(Cardboard Box)		 Image Mode: Grayscale
Interval(mm): 0.06
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 9000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.1
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 70		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 35		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 60		 ×
A4 Paper
(Not White)		 Image Mode: Grayscale
Interval(mm): 0.06
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 60		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 9000mm
Power Min(%): 0 | Power Max(%): 100		 Image Mode: Grayscale
Interval(mm): 0.05
Speed(mm/m): 3000mm
Power Min(%): 0 | Power Max(%): 15		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 35		 Image Mode: Grayscale
Interval(mm): 0.12
Speed(mm/m): 20000mm
Power Min(%): 0 | Power Max(%): 40		 ×

For more LightBurn engraving settings, please download LightBurn Settings PDF Document Below.

LightBurn-Einstellungen zum Schneiden

Materials LU2-2 (≤2.1W) LU2-4-SF/LF (=5W) LU2-10A (=10W) LU3-20A/B (=20W) LU3-40A (=40W) LR2-4B (=2W)
♦ MDF
3mm 		× Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 4
 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 400mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 800mm
Power Min(%): 100
Perform Multiple Passes: 2		 ×
5mm × Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 10		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 600mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 600mm
Power Min(%): 100
Perform Multiple Passes: 3		 ×
♦ Plywood
1.6mm
× Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 600mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 1600mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
2.8mm × Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 1100mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
5mm × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 350mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 700mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
8mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 200mm
P
ower Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 400mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
10mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 8		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
15mm × × × Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
♦ Pine
3mm		 × Image Mode: Line
Speed(mm/m): 150mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 700mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
5mm × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 350mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 500mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
8mm × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 200mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 300mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
10mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 150mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 250mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
12mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 1		 Image Mode: Line
Speed(mm/m): 180mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
15mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 5		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 2		 Image Mode: Line
Speed(mm/m): 150mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×
19mm × × Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 8		 Image Mode: Line
Speed(mm/m): 100mm
Power Min(%): 100
Perform Multiple Passes: 3		 Image Mode: Line
Speed(mm/m): 120mm
Power Min(%): 100
Perform Multiple Passes: 1		 ×

For more LightBurn cutting settings, please download LightBurn Settings PDF Document Below.

Beginnen Sie mit Ortur zu erstellen!

LightBurn Einstellungen PDF herunterladenLightBurn-Software herunterladen
  • Bitte beachten Sie, dass Gravur- und Schneideergebnisse selbst bei demselben Material je nach Oberfläche, Farbe und Dicke variieren können.
  • Um optimale Leistung zu erzielen, passen Sie die Geschwindigkeit, Leistungseinstellungen und Brennweite sorgfältig an – dabei sollte der Brennfleck so klein und präzise wie möglich sein. Bestimmte Materialien wie glänzende Metallplatten, transparente oder reflektierende Oberflächen sowie einige weiße oder lichtdurchlässige Materialien können nicht direkt graviert oder geschnitten werden; in diesen Fällen ist es notwendig, mit einem schwarzen Marker eine Gravuroberfläche zu schaffen.
  • Beaufsichtigen Sie den Lasergravierer während des Betriebs stets, um Brandgefahren zu vermeiden, und halten Sie einen Feuerlöscher in der Nähe bereit. Für detaillierte Anleitungen konsultieren Sie bitte die offiziellen Benutzerhandbücher und Tutorials von Ortur.
